S220S-24P4JX

Switching capacity 98 Gbit/s
Packet forwarding rate 73 Mpps
GE RJ45 24 (PoE+) (1G/100M/10M)
2.5G SFP 2 (2.5G/1G/100M)
10G SFP+ 2 (10G/1G/100M)
PoE Supported
Maximum PoE power consumption [W] 400
Certification EMC certification Safety certification Manufacturing certification
Chassis material Metal
Static power consumption [W] 18.74
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442 mm x 220 mm (1.72 in. x 17.40 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442 mm x 227 mm (1.72 in. x 17.40 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Installation type Rack mounting,Desk mounting,Wall mounting
Weight without packaging [kg(lb)] 2.8 kg (6.17 lb)
Weight with packaging [kg(lb)] 3.71 kg (8.18 lb)
Typical power consumption [W] 33.32
Maximum power consumption [W] – Without PoE: 38.58 W – Full PoE load: 482.55 W (PoE: 400 W)
Number of fans modules 2
Long-term operating temperature [°C(°F)] –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Power supply mode AC built-in
Input voltage range [V] – AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz – High-voltage DC input: 190 V DC to 290 V DC
Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV
Types of fans Built-in
Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment
Airflow direction Air intake from left and front, air exhaustion from right
